Product Details:
|
| Product Name: | Household Portable Prganant Fetal Doppler | Display Size: | 4.5cm |
|---|---|---|---|
| Auto Power Off: | Yes | Net Weight: | 156g |
| Weight: | 200g | Box Size: | 18*10.5*4cm |
| High Light: | Fetal Heartbeat Detector 3.0MHz,doppler fetal heart detector 3.0MHz,Fetal Heartbeat Detector Doppler High Sensitivity |
||
Household Fetal Heart Rate Monitor Doppler Fetal Movement Maternal Fetal Heart Rate Monitor
Product Description:
Fetal Doppler is used for detect the Fetal Heart Rate ( FHR ) to hear the sound of 12 weeks pregnancy in hospital, clinic even at home.
Ultrasonic working frequency: 3.0MHz (2.5MHz and 2.0MHz are optional, the deviation from the nominal rated acoustic working frequency is not more than ±5%.
Comprehensive sensitivity: at a distance of 200mm from the probe surface, the comprehensive sensitivity is not less than 90dB.
Display range: fetal heart rate measurement display range 65bpm-210bpm. In the range of 65-210bpm, the error: ±2bpm (digital type).
Ultrasonic output power: <20mW.
Space peak time peak sound pressure: <0.1MPa
The effective area of the sensitive components of the ultrasonic transducer is: 1.57 cm2±30%.
Fetal heart rate detection resolution is 1bpm
The error of fetal heart rate measurement is not more than ±2bpm
Electromagnetic Compatibility: Group I Class B
Dimensions: 128mmx96mmx30mm
Auto power off: 60s without operation
Quality assurance
Product Features:
Intelligent noise reduction
High sensitivity
Accurate calculation
High sensitivity probe
Clearer measurement
Medical quality
Large screen display
Clear fetal sound
Product Specification:
| Product Name | Portable pregnant fetal doppler |
| Ultrasound Frequency | 3.0MHz±10% |
| Measure Range | 50~210bpm |
| Sensitivity |
12 weeks gestation |
| Ultrasonic Output Power | 20mw |
| FHR Accuracy | ±2bpm |
| Waterproof Grade | IP5 dustproof and waterproof grade |
| Audio Out Socket | 2.5mm |
| Audio Output Power | <0.5W |
| Packing | 1 x Pocket Fetal Doppler 1 x English user's manua 1 x 3.0 Mhz Probe 1 x Original packaging box |
| Warranty | 1 year |
| After-sale Service | Online technial support |
| OEM | Accepted |
Packing Picture
